Joypo 5kwh 10kwh Rack Mounted Lithium Ion Storage Battery For Solar
SystemEnergy storage batteries are necessary in home solar power
generation systems. Here are some of the main reasons:
1. Energy independence: Solar power systems can provide clean,
renewable electricity to homes by converting solar energy into
electricity. However, solar power generation is unstable because it
is affected by sunlight intensity, weather conditions and seasonal
changes. Energy storage batteries can store excess solar energy for
use when solar energy is unavailable or insufficient, making the
home self-sufficient.
2. Savings on electricity bills: Energy storage batteries allow
households to store solar energy during periods of high electricity
prices, such as peak electricity prices, and use the stored energy
when electricity prices are lower or solar energy is unavailable.
This optimizes energy use and reduces household electricity bills.
3. Grid failure backup: In traditional solar power generation
systems, when the grid fails, the system will also stop working to
ensure safety. However, if a home has an energy storage battery
system installed, it can continue to provide power to the home when
the power grid fails, improving the home's power supply reliability
and emergency backup capabilities.
4. Smooth power fluctuations: Solar power systems are affected by
changes in sunlight, causing fluctuations in power output. Energy
storage batteries can smooth these power fluctuations, provide
stable power output and reduce dependence on the grid.
5. Environmentally friendly: Energy storage batteries can help
households reduce dependence on traditional power grids and reduce
the use of fossil fuels, thereby reducing greenhouse gas emissions
and reducing negative impacts on the environment.
| Item | Specification |
| Boundary dimension | L480*W442*H178mm |
| Serial-Parallel Mode | 16S1P |
Basic parameter | Nominal voltage | 51.2 V |
| Typical capacity | 100 Ah(5120 Wh) |
| Inner resistance | ≤65 mΩ |
| Working voltage range | 44.8~57.6 V |
Charging input | Charge method | CC&CV |
| Charge voltage | 58.4 V |
| Standard charge current | 50 A |
| Max. continuous charge current | 100 A |
Discharging output | Discharge cut-off voltage | 42 V |
| Standard discharge current | 50A |
| Max. continuous discharge current | 100 A |
| Main shell material | SPCC |
| IP class | IP51 |
| Cooling method | Air cooling |
| Communication | CAN/RS485/DRY CONTACT |
| Net weight | Approx 45kg |
Environmental requirement | Operation temperature range | Charge:0℃~45℃ Discharge:-20℃~60℃ |
| Storage temperature range | 15℃~25℃:≤12 Months 0℃~35℃:≤3 Months -20℃~45℃:≤1 Months |
| Storage humidity | 15%-85%RH |
FAQ:
1. Can I have a sample order?
Re: Yes, the sample order is welcome here, so you can test the
product quality.
2. How long is the lead time?
Re: Sample order takes around 7-20 days, bulk order takes 20-35
days, depending on the order size and production schedule.
3. How long is the battery warranty?
Re: 5 years, can be extended for large orders.
4. Can you supply the charger for the battery?
Re: Yes, if you need the charger, please tell us before ordering,
for the charger cost is not included in the battery price.
5. How can you guarantee the quality?
Strict Quality Checks: Multiple rounds of strict quality checks
during manufacturing. Each battery is carefully inspected to meet
and exceed industry standards.
High-Quality Materials: This includes advanced cell technologies
and materials that are proven to deliver superior energy density,
longer cycle life, and stable performance.
Customer Feedback: Our customers' satisfaction is a testament to
the quality of our batteries. Positive reviews and long-term
customer relationships underscore our commitment to delivering on
our promises.
Warranty: A long-term warranty not only protects your investment
but also reflects our confidence in the durability and performance
of our batteries.
We understand the importance of earning your trust, and we are
committed to delivering a product that exceeds your expectations.
Should you have any further questions or concerns, please feel free
to reach out to our customer service team. We look forward to the
opportunity to serve you and provide you with reliable,
high-quality batteries.
